Pacific Scientific Instruments, an ISO9001 Certified company,manufactures the HIAC,Royco,Metone, and HYT brands of optical particle counting instrumentation,software and accessories
Model 227A/ 227B
Handheld Airborne particle Counter
- Battery-operated handheld - 0.3 or 0.5 micron sensitivity at 0.1 cfm
- Counts 2 sizes simultaneously - 5 counting modes
- RS-232 to computor or printer
Model 228/229
Particle Concentration Meter / Counter
- Battery-operated handheld - 0.3 or 0.5 micron sensitivity at 0.1 cfm
- Quick evalutions of rooms or filters
- Bright Red LED display for counts - Only 1.5 pounds (0.65kg.)
Model 237A/ 237B
Portable Airbone Particle Counter
- Battery-operated portable - 0.3 or 0.5 micron sensitivity at 0.1 cfm
- Counts 2 to 6 sizes simultaneously - 4 counting modes
- Built in printer
Model 2400 / 2408
Airbone particle counter
-0.3 or 0.5 micron sensitivity at 1 cmf - Counts 2 to 5 sizes simultaneously
-209E calculations - Built in printer
- supports manifold, up to 32 ports - 4 counting modes
Model 3313 / 3315
Airbone Particle Counter
- Battery operation for up to 3 hours continous
- 0.3 or 0.5 micron sensitivity at 1 cmf - Counts 6 sizes simultaneously
- ISO 14644-1 calculations - 209E calculations - built in printer
Model 2813 / 2815
Airbone Particle Counter
-0.3 or 0.5 micron sensitivity at 1 cmf - Counts 4 sizes simultaneously
- 209E calculations - Barcode entry for precision and repeatability
Model 237H
Portable Airborne Paricle Counter
- 0.10 µm minimum threshold setting at 0.1 cfm
- Two to six size channels - Four counting modes
- Process gas model
Model 2100c / 2200c
Airborne particle Counter
-0.1 or 0.2 micron sensitivity at 1 cfm - Supports, manifold, up to 32 ports
- 209E calculations - counts 6 sizes simultaneously - Built in printer
Model CNC 1100 Series
Consideration Nucleus Counter
- Superior sensitivity at high flow rates
- Safe sampling of oxygen and hydrogen
- portability
Model 1101 remote CNC
Remote Condensation Nucleus Counter
- Superior sensitivity (10 nm and larger)
- Remote Control and Data Retrieval
- cost Effective - Small Dimensions
Model R2313 / R2315
Remote Particle Counters
-Built in pump with 1.0 cfm flow rate - optional remote display
-316L stainless steel enclosure - 0.3 micron or 0.5 micron
Model 8801 / 8901
Remote Particle Counters
- 0.1 micron at 0.1 cfm - High-reliability DPSSL laser system technology
- 2, 4, or 5 channels - Stainless steel enclosure
Model 2432
Particle Counting Manifold
- Random location sequencing
- High flow purge through all samples
- Meets applicable Fed-Std-209E requirements
Model 4900 Series
Remote Airborne Particle Counters
- 0.3 or 0.5 µm minimum threshold setting
-0.1 cfm flow rate - Two size channels
-4-20mA output - Delayed alarm
Model 5800 Series
High Flow Remote Particle Counters
- 0.3 µm at 1 cfm - 9-28VDC input
- 1 cfm flow rate - 2 size channels
- stainless steel case - RS485 communications
Model 5900 Series
High Flow Remote Particle Counters
- 0.3 µm at 1 cfm - 9-28VDC input
- 1 cfm flow rate - 2 size channels
- stainless steel case - 4-20 mA output
Model 237D
Laser-based Airborne Particle Counter
- 0.5 µm at 1 cfm flow rate (0.3 µm at 0.1 cfm)
- 2 size channels - Local display - stainless steel NEMA enclosure
- Allows users to perform standard cleaning processes
Model R4000 Series
Remote Airborne Particle Counting Sensor
- Remotely count 0.1 µm particles
- RS485 serial communications
Model 4800 Series
Remote Airborne Particle Counters
- 0.3 µm minimum threshold setting
- 0.1 cfm flow rate
- Two size channels- RS485 serial communications
Airborne Accessories
- Isoprobes, Wallplates, Alarms Modules, High Pressure Diffuser, etc
- Enviornmental Sensors & Multiplexers/PLC
-Accessories for single counters
-Accessories for manifold systems
 |
 |
 |
 |
 |
 |
 |
